Snail Tools HSS Co Single Flute End Mill (6 x 8 x 50 x 100MM)

Snail Tools HSS Co Single Flute End Mill (6 x 8 x 50 x 100MM)

or
Call +1 437 475 2301

Description

Maximum Cut Length Precision Cobalt End Mill (6mm Dia, 50mm Cut Length) for High-Speed Machining of Aluminum and Non-Ferrous Metals in Canada.

The Snail Tools HSS Co Single Flute End Mill (6 x 8 x 50 x 100MM) is a specialized tool designed for highly efficient, high-speed material removal, particularly in aluminum, brass, and plastics. This cutter features a maximum cutting depth for its size, combined with an overall length suitable for deep reach applications while maintaining superior rigidity. The single flute design allows for maximum chip clearance and evacuation, crucial for preventing material adhesion and ensuring a smooth finish during intricate CNC applications across Ontario and the GTA.

Key Features & Optimized Performance

  • Design: 1 Flute (Single Flute) – Provides the largest chip valley, essential for very high feed rates and fast evacuation of soft materials, minimizing material sticking and friction.
  • Material: HSS Co (High-Speed Steel with Cobalt) alloy construction ensures superior hardness, allowing the cutter to maintain its sharp edge and structural integrity during high-speed machining.1
  • Stabilized Shank: Features a larger 8 mm Shank Diameter (d) than the cutting diameter, providing enhanced stability and rigidity for the 6 mm Cut Diameter (D), which minimizes vibration and improves cut quality, especially over long cuts.
  • Maximum Cut Length: The substantial 50 mm Length of Cut (B) allows for exceptionally deep slotting and profiling operations.
  • Application: Ideal for deep pocketing, through-hole slotting, and routing in non-ferrous metals and plastics, delivering an exceptionally clean surface finish.

    • Technical Specifications

    Trust Snail Tools to deliver the speed, precision, and maximum cutting depth required for superior machining of non-ferrous materials in your professional projects.

    Show All

    Specifications

    ConditionNew
    DetailMeasurement Equivalent
    Flutes1 Single Flute
    Shank Diameter (d)8 mm 5/16 inch approx.
    Cut Diameter (D)6 mm 0.236 inches approx.
    Length of Cut (B)50 mm 2 inches approx.
    Overall Length (L)100 mm 4 inches approx.
    Material GradeHSS Co (Cobalt)
    Code(Please provide a product code if available, e.g., 089)
